NHTSA ID Number: 10161687
Manufacturer Communication Number: 19-AT-003H-1
Summary
This bulletin provides the procedure to identify the correct transmission part number for 2013~14 Sonata (YFa) 2.4L by referring to the Serial Code. Some transmissions installed during the transition from 2013 to 2014 model years may be mixed from 8/20/2013 to 10/17/2013.
2 Affected Products
Vehicle
| MAKE | MODEL | YEAR |
HYUNDAI | SONATA | 2013-2014 |
Description: This bulletin provides the procedure to identify the correct transmission part number for 2013~14 Sonata (YFa) 2.4L by referring to the Serial Code.
Some transmissions installed during the transition from 2013 to 2014 model years may be mixed from 8/20/2013 to 10/17/2013.
NOTE: An incorrect transmission part number may cause a 2-3 shift flare.
Parts Information:
| Vehicle | Serial Code (1st 4) | ATM | ECU | TCU CAL ID |
| 2013~14 Sonata (YFa) 2.4L | FA*N | 45000-3BEB0 | 39111-2G673 | TYF0Z24NA9 |
| FA*X | 45000-3BKN0 | 39111-2G678 | TYF0Z24SA8 |
NUMBER
19-AT-003H-1
DATE
MAY, 2019
Loading...
Reload document
Open in new tab
- For use in 95% of vehicles including most CVTs in operation with US registered light duty applications
- High performance conditioning agents prolong seal elasticity to prevent leaks
- Improved durability & transmission life with anti-wear technology to avoid costly repairs
- Enhanced high & low temp performance supports transmission fluid in all weather situations
- Full synthetic formula with advanced additives protects against transmission breakdown better than conventional fluids
- Provides outstanding resistance to oxidation, sludge, and varnish deposits at extreme temperatures
- Reduces wear or scoring of gears, clutch bands and discs
- Provides excellent friction control for smooth shifting and a cooler running transmission
- Allows maximum engine performance and protection at all operating temperatures
- Specially formulated using only the finest lubricating oils and a technologically advance additive system
- Authentic Original Equipment Manufacturer (OEM) part
- OEM quality
- Exact part that came with your car
- Direct fit
- Formulated with full-synthetic base stocks and advanced additive technology to meet the challenging demands of automatic transmissions
- Enhanced anti-shudder protection for smooth shifting and maximum power transfer
- Developed with anti-wear technology to help improve transmission durability
- Engineered with a proprietary blend of base oils and advanced additives to provide better oil flow at low temperatures and greater film protection at higher temperatures
- Precisely engineered frictional characteristics smooth shifting and outstanding anti-shudder performance
- Excellent resistance to oxidation and thermal breakdown provides long fluid life and extended protection
- Provides superior cleanliness, keeping the transmission free of sludge and varnish deposits
- Advanced anti-wear technology provides maximum protection to gears and bearings
- Excellent seal compatibility and conditioning reduces risk of fluid leaks due to seal shrinkage, hardening and cracking
- Compatible for Hyundai/Kia Vehicles: Specifically formulated to meet the SP-III specification required by Hyundai and Kia vehicles, enhancing transmission reliability and performance.
- Enhanced Driving Performance: Offers smoother shifting and enhanced driving performance, ensuring a comfortable and responsive ride.
- Smooth Shifting Performance: This ATF fluid maintains engine gear efficiency, preventing sludge and varnish buildup for smooth operation under both city and highway conditions.
- Extend Transmission Life: Idemitsu ATF fluid resists oxidation and thermal breakdown, enhancing durability and reducing the need for frequent repairs.
- Engine Protection and Stability: Offers superior seal compatibility and conditioning, protecting gears and bearings and reducing fluid leaks for confident driving.
- Engineered to help alleviate typical problems experienced by transmissions with over 75,000 miles such as leaks and rough shifts
- Additional seal conditioners to prevent or help stop leaks
- Extra cleaning agents to reduce varnish and sludge formulation
- For use in most Honda, Acura, Toyota, Nissan, Mazda, Volvo and other imported vehicles
- Exceeds the requirements of the JASO-1A performance standard created by Japanese Automobile Manufacturers; This standard is recognized by Japanese OEMs in certifying ATF for use in their vehicles
- For most automatic and & continuously variable transmissions including Ford, GM, Chrysler and Asian Imports
- Enhanced friction durability for smooth transmission performance
- Superior high temperature protection to effectively resist oxidation
- Unsurpassed protection against copper corrosion
SEOCONTENT-START
Circulate To: Service Manager, Warranty Manager, Service Advisors, Technicians, Fleet Repair
Technical Service Bulletin
GROUP NUMBER
AUTOMATIC
TRANSMISSION 19-AT-003H-1
DATE MODEL(S)
MAY, 2019 SONATA (YFa)
SUBJECT: AUTOMATIC TRANSMISSION 2-3 SHIFT FLARE
This TSB supersedes TSB 19-AT-003H to revise the Parts Information.
Description: This bulletin provides the procedure to identify the correct transmission part
number for 2013~14 Sonata (YFa) 2.4L by referring to the Serial Code.
Some transmissions installed during the transition from 2013 to 2014 model years may be mixed
from 8/20/2013 to 10/17/2013.
NOTE: An incorrect transmission part number may cause a 2-3 shift flare.
Applicable Vehicles: 2013~14 Sonata (YFa) 2.4L 2013~14 Sonata (YFa)
If an installed transmission has a 2-3 shift
flare:
Locate the 12 digit Serial Code of the
removed transmission at the location shown
in the image.
Refer to Parts Information to confirm the
installed transmission was the correct part
number according to the first 4 digits of the
serial code. If the installed transmission was:
Incorrect ATM, install the correct ATM.
Correct ATM, replace the ECU according
to the Parts Information below.
Parts Information:
Vehicle Serial Code (1st 4) ATM ECU TCU CAL ID
2013~14
Sonata(YFa) 2.4L
FA*N 45000-3BEB0 39111-2G673 TYF0Z24NA9
FA*X 45000-3BKN0 39111-2G678 TYF0Z24SA8
Warranty Information: Normal Warranty Applies
Service Procedure:
1. Remove the air filter box and locate the Serial Code on top of the transmission.
Refer to the Parts Information to determine the correct transmission.
SEOCONTENT-END
